Adjustable Metalworking CNC Workholding Fixture For Machining Operations

Product Description:

The CNC Workholding Fixture is an essential tool designed to provide precision, stability, and efficiency in machining operations. With its robust construction and high-quality materials, this clamping fixture is engineered to meet the demanding requirements of modern CNC machining processes. Measuring 350x350x30mm, this fixture offers a compact yet versatile platform that can accommodate a wide range of workpieces, making it an indispensable accessory in any machine shop or manufacturing facility.

One of the standout features of this CNC clamping fixture is its ability to securely hold workpieces up to a maximum size of 300mm x 200mm x 150mm. This capacity ensures that it can handle a variety of parts and components, from small precision parts to moderately sized workpieces. The fixture's design prioritizes both strength and flexibility, allowing operators to position and secure their materials with confidence, minimizing movement and vibration during machining.

Durability is a key attribute of this CNC clamping fixture, as evidenced by its impressive hardness rating of HRC57°. This high hardness level ensures that the fixture maintains its shape and clamping force even under rigorous use, resisting wear and deformation over time. This resilience translates to consistent performance and longer service life, providing excellent value for manufacturers who rely on precision and repeatability in their production processes.

Flexibility is another critical aspect of this CNC clamping fixture. It features a design that allows for quick and easy exchange of components, enabling operators to switch between different workpieces or setups rapidly. This flexible exchange capability reduces downtime and increases productivity, making it ideal for environments where multiple parts and frequent changeovers are common. The fixture’s adaptability helps streamline workflow and enhances overall efficiency on the shop floor.

In addition to its size and flexibility, the fixture boasts a remarkable clamping torque of 18 KN. This significant clamping force ensures that workpieces are held firmly in place throughout the machining process, preventing any unwanted movement that could compromise accuracy or surface finish. The strong torque capacity makes this CNC clamping fixture suitable for heavy-duty applications, where maintaining exact positioning under high cutting forces is crucial.

As a dedicated cnc clamping fixture, this product is designed with precision engineering and user-friendly features that cater to both novice and experienced machinists. Its thoughtful design includes easy-to-use clamping mechanisms that facilitate quick setup while maintaining a secure grip on the workpiece. This combination of ease-of-use and robust performance makes it a reliable choice for a wide range of CNC machining tasks.

Whether used in aerospace, automotive, electronics, or general manufacturing, this cnc clamping fixture enhances machining accuracy and repeatability. It supports improved throughput by reducing setup times and minimizing errors associated with workpiece movement. By investing in this fixture, manufacturers can ensure higher quality parts, reduce scrap rates, and optimize their machining operations for better overall productivity.

In summary, the CNC Workholding Fixture with its dimensions of 350x350x30mm, maximum workpiece capacity of 300mm x 200mm x 150mm, hardness rating of HRC57°, flexible exchange capabilities, and a powerful clamping torque of 18 KN, represents a high-performance solution for modern CNC machining needs. Its combination of strength, precision, and adaptability makes it a valuable asset in achieving superior machining outcomes. For anyone seeking a reliable and efficient cnc clamping fixture, this product delivers exceptional quality and performance, helping to elevate manufacturing standards and operational efficiency.

Applications:

The AST 96 Series CNC Workholding Fixture, originating from China, is a highly reliable and versatile solution designed to meet the rigorous demands of modern machining environments. Its ground and polished surface finish not only ensures a smooth and precise contact surface but also contributes to its exceptional durability and corrosion resistance, thanks to an advanced anti-rust coating treatment. This makes the fixture ideal for use in environments where longevity and consistent performance are critical.

One of the standout features of the AST 96 Series is its flexible exchange capability, allowing for quick and easy exchange fixture operations. This flexibility significantly reduces downtime during tooling changes, boosting productivity in manufacturing processes. The fixture supports OEM customizations, enabling it to be tailored to specific machining requirements and applications, thus enhancing its adaptability across different production lines.

The 4-axis clamping fixture design incorporated in this series provides superior stability and precision when securing workpieces. This is crucial for complex machining tasks that require multi-directional access and positioning. The repeat position accuracy of 0.005mm guarantees that each workpiece is held with exactness, ensuring consistent machining quality and reducing the need for rework. Such precision is vital in industries where tight tolerances are mandatory.

Application occasions for the AST 96 Series CNC Workholding Fixture include high-volume manufacturing, aerospace component production, automotive parts machining, and any scenario demanding quick fixture exchange and precision clamping. It is particularly useful in setups where multiple parts need to be machined sequentially or simultaneously with minimal setup time. The corrosion-resistant coating further extends its usability in environments exposed to moisture or cutting fluids.

In summary, the AST 96 Series exchange fixture offers a robust, precise, and efficient clamping solution for CNC machining applications. Its flexible exchange fixture design, combined with 4-axis clamping capability and high repeat positioning accuracy, makes it an indispensable tool for manufacturers seeking to optimize their machining operations while maintaining high-quality standards.

Customization:

AST's 96 Series CNC Workholding Fixture offers exceptional customization services to meet your precise machining needs. Manufactured in China, this clamping fixture features a ground and polished surface finish, ensuring durability and high precision during operation. With a repeat position accuracy of 0.005mm, it guarantees consistent and reliable performance for your production processes.

Designed for flexibility, the 96 Series allows for quick and easy exchange, making it an ideal solution for dynamic machining environments. Its multi-position base enhances versatility, enabling efficient setup changes and supporting complex machining tasks. We also provide customization options tailored to optimize the 5axis clamping tool compatibility, ensuring seamless integration with your CNC equipment.

Weighing 12 Kg, this CNC Workholding Fixture balances robust construction with manageable handling. Trust AST to deliver customized workholding solutions that enhance productivity and precision in your manufacturing operations.

Support and Services:

Our CNC Workholding Fixture is designed to provide precision, stability, and efficiency for your machining operations. To ensure optimal performance and longevity of the product, we offer comprehensive technical support and services tailored to your needs.

Technical Support:

Our team of experts is available to assist you with installation guidance, troubleshooting, and maintenance tips. We provide detailed manuals and setup instructions to help you integrate the fixture seamlessly into your CNC machining processes. Should you encounter any issues, our support staff will work closely with you to diagnose and resolve problems promptly.

Services:

We offer customization services to tailor the workholding fixture to your specific application requirements. This includes modifications in size, clamping mechanisms, and material compatibility. Additionally, we provide repair and refurbishment services to extend the life of your fixture, ensuring it continues to deliver precise and reliable performance.

Training and Consultation:

To maximize the benefits of your CNC Workholding Fixture, we offer training sessions for your operators and engineers. These sessions cover best practices for setup, operation, and maintenance. Our consultants are also available to help optimize your workholding strategies for improved productivity and reduced cycle times.

By choosing our CNC Workholding Fixture, you gain access to a full suite of support and services designed to enhance your manufacturing capabilities and ensure your investment delivers the highest value.

Packing and Shipping:

Each CNC Workholding Fixture is carefully packaged to ensure maximum protection during transit. The fixture is first secured with protective foam padding to prevent any movement inside the box. It is then placed in a sturdy, corrugated cardboard box designed to withstand shipping impacts.

For added safety, the packaging includes anti-corrosion paper to protect the metal surfaces from moisture and rust. All components are individually wrapped and labeled to facilitate easy identification and assembly upon delivery.

Shipping is handled through reliable carriers with tracking options available to ensure timely and secure delivery. We also offer custom packaging solutions for bulk orders or special requirements to meet specific customer needs.

Upon receipt, customers are advised to inspect the package for any visible damage and report any issues immediately to ensure prompt resolution.
